Introducing a new family of multi-channel electrocardiographs that are flexible enough to work in any setting. These reliable, easy-to-use devices were designed using proprietary Welch Allyn technology to make taking ECGs a snap. With an intuitive design and advanced software features, these EMR-ready devices can help make your practice more efficient by allowing you to quickly administer patient tests and manage patient information.

FEATURES & BENEFITS

A 12-lead resting ECG that provides accurate measurements.
Optional MEANS ECG interpretation software for a second opinion.
High-resolution thermal printer generates full-sized standard and customized reports.
Lead quality graphic saves valuable time by highlighting poor connections.
Full alphanumeric keyboard and LCD display for fast and easy entry of patient information.
Advanced filters for optimal ECG trace quality ensure accurate readings.
Customizable report formats allow you to print information the way you need.
Battery operation lets you easily transport your device to the patient.
Instant-on feature powers the device up quickly and lets you take an ECG at a moment’s notice.
Large color LCD screen allows you to easily preview critical information on screen.
Save time by using dedicated function or “hot keys” to perform the most common functions without scrolling through menus.
Store up to 50 ECGs for later review and editing of patient data and interpretation.
Easily connect directly to Welch Allyn CardioPerfect™ Workstation Software through cable interface.
Use Schedule Test mode to program all patient information in at the beginning of the day so that you can use your time more efficiently.
Administrative functions with password log-on controls to support your program for HIPAA compliance.
EMR-ready devices can easily transfer patient information and test results to the patient’s electronic medical record for analysis and long-term storage.

TECHNICAL SPECIFICATIONS

Dimensions: 16.2" W x 15.6" D x 6.2" H
Weight: 11.6 lb (5.3 kg) including battery
Waveform Display: Color, text and ECG waveform
Thermal Recorder: Computer-controlled dot array, 8 dots/mm
ECG Storage: Up to 50 ECGs and tests
Frequency Response: 0.3 to 150 Hz
Digital Sampling Rate: >1,000 s/second/channel
CMRR: Meets or exceeds EC11, typically 80 dB
Input Impedance: 47 MΩ DC
Power Requirement: Universal AC power supply (100-240 VAC at 50/60 Hz) 65 VA
